型號	交換容量	包轉發率	業務端口描述	外形尺寸（寬×深×高）（單位：mm）	管理用以太網口	USB口	串行CONSOLE口
S5130S-30C-EI-G	672Gbps/6.72Tbps	171Mpps/260Mpps	24個10/100/1000Base-T自適應以太網接口，4個萬兆SFP+接口	440×360×44	1	1	1
S5130S-54C-EI-G	672Gbps/6.72Tbps	207Mpps/260Mpps	48個10/100/1000Base-T自適應以太網接口，4個萬兆SFP+接口	440×360×44
S5130S-36S-EI-G	672Gbps/6.72Tbps	171Mpps/260Mpps	28個10/100/1000Base-T自適應以太網接口，8個萬兆SFP+接口	440×260×44
S5130S-54S-EI-G	672Gbps/6.72Tbps	207Mpps/260Mpps	48個10/100/1000Base-T自適應以太網接口，6個萬兆SFP+接口	440×260×44
S5130S-36F- EI-G	672Gbps/6.72Tbps	171Mpps/260Mpps	28個SFP以太網光接口(含4個Combo 10/100/1000Base-T自適應以太網接口)，8個萬兆SFP+接口	440×260×44
S5130S-36S-PWR-EI-G	672Gbps/6.72Tbps	171Mpps/260Mpps	28個10/100/1000BASE-T PoE+電口,8個1G/10G BASE-X SFP Plus端口	440×320×43.6
S5130S-54S-PWR-EI-G	672Gbps/6.72Tbps	207Mpps/260Mpps	48個10/100/1000BASE-T PoE+電口,6個1G/10G BASE-X SFP Plus端口	440×320×43.6
